Accelight’s CFP2 transceiver module is designed for 100 Gigabit Ethernet & OTU4 links over 10Km singlemode fiber. The module has 4 independent electrical input/output channels, and the operating speed of each channel is up to 28Gbps. This transceiver consists of transmitter and receiver units and operates on a set of 4 wavelengths near 1310nm on the ITU G.694.1 LAN-WDM grid. The transmitter unit contains a Tx CDR, a 4-channel modulator driver and a 4-channel EML. On the receiver path, there are a 4-channel PIN arrays and a 4-channel TIA arrays, as well as Rx CDR.

Accelight’s CFP2 transceiver module is designed for 100 Gigabit Ethernet & OTU4 links over 40Km singlemode fiber. The module has 4 independent electrical input/output channels, and the operating speed of each channel is up to 28Gbps. This transceiver consists of transmitter and receiver units and operates on a set of 4 wavelengths near 1310nm on the ITU G.694.1 LAN-WDM grid. The transmitter unit contains a Tx CDR, a 4-channel modulator driver and a 4-channel EML. On the receiver path, there are one VOA+SOA components, a 4-channel PIN arrays and a 4-channel TIA arrays, as well as Rx CDR

Accelight’s CFP2 transceiver module is designed for 100 Gigabit Ethernet & OTU4 links over 80Km singlemode fiber. The module has 4 independent electrical input/output channels, and the operating speed of each channel is up to 28Gbps. This transceiver consists of transmitter and receiver units and operates on a set of 4 wavelengths near 1310nm on the ITU G.694.1 LAN-WDM grid. The transmitter unit contains a Tx CDR, a 4-channel modulator driver and a 4-channel EML. On the receiver path, there are one VOA+SOA components, a 4-channel PIN arrays and a 4-channel TIA arrays, as well as Rx CDR

Accelight’s QSFP28 BIDI transceiver module is designed for use in 100 Gigabit Ethernet links over 10km single mode fiber. The module incorporates 1 channel optical signal, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI28G-VSR and QSFP28 MSA

Accelight’s QSFP28 BIDI transceiver module is designed for use in 100 Gigabit Ethernet links over 30km single mode fiber. The module incorporates 1 channel optical signal, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI28G-VSR and QSFP28 MSA.

Accelight’s QSFP28 CWDM LR1 Single Lambda QSFP28 transceiver module is designed for use in 100 Gigabit Ethernet links over 10km single mode fiber. The module incorporates one channel optical signal, on 1271, 1291, 1311 or 1331nm center wavelength, operating at 100Gpbs data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA

Accelight’s QSFP28 transceiver module is designed for 100 Gigabit Ethernet links over 500m single mode fiber. The module incorporates 1 channel optical signal, on 1311nm center wavelength, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA.

Accelight’s QSFP28 transceiver module is designed for 100 Gigabit Ethernet links over 2km single mode fiber. The module incorporates 1 channel optical signal, on 1311nm center wavelength, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA.

Accelight’s QSFP28 transceiver module is designed for 100 Gigabit Ethernet links over 10km single mode fiber. The module incorporates 1 channel optical signal, on 1311nm center wavelength, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA.

Accelight’s QSFP28 transceiver module is designed for use in 100 Gigabit Ethernet links over 40km single mode fiber. The module incorporates 1 channel optical signal, on 1309nm center wavelength, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA. inserting the optical fiber, it is recommended to clean the end of the optical fiber connector to avoid contamination of the module optical port due to dirty connector. If contamination occurs, use standard LC port cleaning methods
