100G QSFP28 ER1
Accelight’s QSFP28 transceiver module is designed for use in 100 Gigabit Ethernet links over 40km single mode fiber. The module incorporates 1 channel optical signal, on 1309nm center wavelength, operating at 100Gbps data rate. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA. inserting the optical fiber, it is recommended to clean the end of the optical fiber connector to avoid contamination of the module optical port due to dirty connector. If contamination occurs, use standard LC port cleaning methods
Product Details
  • Product Features
    Supports 100Gbps
    Single 3.3V Power Supply
    100G Lambda MSA 100G-ER1-40 Specificatio Compliant
    Power dissipation < 4.5W
    100Gbps hermetic TOSA with 1309nm EML and APD Detector
    Up to 40km over SMF with FEC
    RoHS compliant
    SFF-8636 Rev 2.10a Compliant
    4x25Gbps Electrical interface
    LC Duplex connector
    Commercial case temperature range of 0°C to 70°C
    I2C interface with integrated Digital Diagnostic Monitoring
  • Applications
    Ethernet networks
    Other optical links
  • Ordering information
