Accelight’s 10G SFP+ BIDI 10km/40km series single mode transceiver is small form factor pluggable module for duplex optical data communications such as 10GBASE-LR/LW defined by IEEE 802.3ae. It is with the SFP+ 20-pin connector to allow hot plug capability Accelight’s 10G SFP+ BIDI 10km/40km module is designed for single mode fiber and operates at a nominal wavelength of 1270nm; 10G SFP+ BIDI 10km /40km module is designed for single mode fiber and operates at a nominal wavelength of 1330nm. The transmitter section uses a multiple quantum well DFB, which is class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC

PRODUCT DETAILS: 1.25G SFP EX 40km SMF LC interface 1.25G SFP ZX (60 80)km SMF LC interface 1.25G SFP EZX (100 120 160)km SMF LC interface

Accelight’s QSFP28 CWDM4 transceiver module is designed for use in 100 Gigabit Ethernet links over 2km with FEC single mode fiber. Digital diagnostics functions are available via an I2C interface, as specified by the QSFP28 MSA.

Accelight’s ASP-PR-GU-20 Series is a transceiver for the optical network unit (ONU) of 10G GPON with 9.95328Gbps in downstream and 9.95328Gbps in upstream. ASP-PR-GU-20 series is high performance module for single fiber communications by using 1270nm burst-mode transmitter and 1577nm continuous-mode receiver. The transmitter section uses a DFB 1270nm laser and the receiver section uses an integrated 1577 nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. CML interface is used for differential inputs and outputs. LVTTL logic control interface simplifies the interfaces to external circuitry.

Accelight’s ASP-PR-GT-DC-30 Series is a transceiver for the optical line terminal (OLT) of XGS-PON/XG- PON with 9.953Gbps in downstream and 9.95328/2.48832Gbps in upstream. ASP-PR-GT-DC-30 series is high performance module for single fiber communications by using 1577nm continuous-mode transmitter and 1270nm burst-mode receiver. The transmitter section uses an EML 1577nm laser and is a class 1 laser compliant according to International Safety Standard IEC-60825-1. The receiver section uses an integrated 1270 nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

Accelight's QSFP56-DD to 2xQSFP56 AOC is designed for use in 400 Gigabit Ethernet links over 30m MMF. QSFP56-DD end of the AOC module has 8 independent electrical input/output channels operating at 53.125Gbps per channel. Each QSFP56 end of the AOC module has 4 independent electrical input/output channels operating at 53.125Gbps per channel. It consists of two transmitter/receiver units, with each operating on 850nm wavelength. The electrical interface of the module is compliant with the 400GAUI-8/200GAUI-4 interface as defined by IEEE 802.3bs, and compliant with QSFP56- DD/QSFP56 MSA.
